Author Topic: Beaulieu 708 HTI Audio
Alan Rik
Film God

Posts: 2211
From: New York City, NY, USA
Registered: Jun 2003


 - posted April 13, 2016 09:21 AM      Profile for Alan Rik   Email Alan Rik   Send New Private Message       Edit/Delete Post
A forum member here posted about audio options on the Beaulieu HTI. While it is true that audio does sound better using the speaker outputs my machine and the other HTI that I use to have did have the ability to play audio through the internal speakers.
It might not be uncommon to have a model that does not have the ability to play audio through its speakers however. I know that when Wittner use to do the HTI mod on the GS1200 they had to remove one speaker because it was a little cramped in there.
And while Beaulieu had their own model 708 that they created from the ground up to be an HTI machine, there were many models that were 'upgraded' to HTI specs.
It could be the model you have is one of these.
However..incredible machine..no? [Smile]

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 13, 2016 09:38 AM      Profile for Andrew Woodcock         Edit/Delete Post
In that case then Alan, surely a simple check, involving removing the rear cover will indicate whether or not this is the case, if I understand your point here correctly?

That way, you'd see if the projector still had it's own internal speakers intact.

[ April 13, 2016, 10:56 AM: Message edited by: Andrew Woodcock ]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Alan Rik
Film God

Posts: 2211
From: New York City, NY, USA
Registered: Jun 2003


 - posted April 13, 2016 11:17 AM      Profile for Alan Rik   Email Alan Rik   Send New Private Message       Edit/Delete Post
There is no speaker according to the ad. Here is the link:
http://www.s8profis.de/beaulieu-stereo-p-371.html

Google translate says:

The speaker was removed and the sound is running

through an external speaker.

A speaker is present with the device does not exist,

on request, we can but a speaker

enclose. (This is not original, and from another brand)

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 13, 2016 12:08 PM      Profile for Andrew Woodcock         Edit/Delete Post
That clears that one up nicely Alan thanks! [Smile]

Lovely machine though.

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Alan Gouger
Master Film Handler

Posts: 451
From: Florida
Registered: Jun 2003


 - posted April 13, 2016 02:28 PM      Profile for Alan Gouger   Email Alan Gouger   Send New Private Message       Edit/Delete Post
That sure does. My transaction was done over the phone with lots of questions over a period of several days and I was assured the audio was fine but it was never mentioned I must use the external speakers only. Yes Andrew the mystery is solved.
This projector is one of a kind special ordered from the factory for a client who sadly did not get to use it very long. The projector is extremely quiet. It allows the use of ether the UHP lamp or switch to the HTI bulb. This thing is bright if using the HTI lamp I wish all projectors had this light output. It does have the 1.1 lens. Thanks Alan for the instructions how to switch the shutter between 2 and 3 blade I can hardly wait to check out the HTI lamp in 2 blade mode. Andrew thanks for your thread and instructions adjusting the screw on the input of the projector. That thread is a good read.
I have several Fumeos but the Beaulieu definitely has it beat in light output and focus stability & accuracy. I am relatively new the Beaulieu but the little time I've spent with it so far I am extremely impressed.
I am glad we have this forum and our friends to turn to when needing help and best of all to share this wonderful hobby with [Smile]

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 13, 2016 02:47 PM      Profile for Andrew Woodcock         Edit/Delete Post
You got a peach of a machine there Alan! You lucky man. [Smile] [Smile] [Smile] [Wink]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Paul Adsett
Film God

Posts: 5003
From: USA
Registered: Jun 2003


 - posted April 13, 2016 03:22 PM      Profile for Paul Adsett     Send New Private Message       Edit/Delete Post
So Alan (Gouger), exactly what does your projector inventory look like these days?

--------------------
The best of all worlds- 8mm, super 8mm, 9.5mm, and HD Digital Projection,
Elmo GS1200 f1.0 2-blade
Eumig S938 Stereo f1.0 Ektar
Panasonic PT-AE4000U digital pj

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 13, 2016 03:26 PM      Profile for Andrew Woodcock         Edit/Delete Post
Lol Paul. Large Paul, very large! [Big Grin] [Wink]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Alan Rik
Film God

Posts: 2211
From: New York City, NY, USA
Registered: Jun 2003


 - posted April 14, 2016 08:17 AM      Profile for Alan Rik   Email Alan Rik   Send New Private Message       Edit/Delete Post
I have projector envy. [Eek!]

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 14, 2016 08:20 AM      Profile for Andrew Woodcock         Edit/Delete Post
You ought not to Alan, with your present collection and back catalogue of these things! [Big Grin] [Big Grin] [Wink]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Paul Adsett
Film God

Posts: 5003
From: USA
Registered: Jun 2003


 - posted April 14, 2016 10:17 AM      Profile for Paul Adsett     Send New Private Message       Edit/Delete Post
Well, I do think it would be nice to know what projectors Alan is using, and what his opinion is of their merits. I did sell him a very nice Eumig 926GL Stereo a couple of years ago, and I believe he was amazed at the sound quality.

--------------------
The best of all worlds- 8mm, super 8mm, 9.5mm, and HD Digital Projection,
Elmo GS1200 f1.0 2-blade
Eumig S938 Stereo f1.0 Ektar
Panasonic PT-AE4000U digital pj

 |  IP: Logged

Alan Gouger
Master Film Handler

Posts: 451
From: Florida
Registered: Jun 2003


 - posted April 14, 2016 02:16 PM      Profile for Alan Gouger   Email Alan Gouger   Send New Private Message       Edit/Delete Post
Paul the Eumig 926GL Stereo you sold me is a very nice projector. I was surprised how quiet and bright the image was, the sound is one of its strengths. It can be a little difficult threading the machine but when everything aligns it is a very nice machine that delivers an image and sound on par with the best of them. Its performance exceeded my expectations.

To answer your other question: I also own a standard GS1200, a Ugo Xenon GS, several Fumeos but my fav is a rare one with stereo & recording and now the Beaulieu HTI.
I like the Fumeo for the fact it has the safest film path, I never fear of scratching my prints with this projector.
The Beaulieu has some nice features lacking in the Fumeo and same with the GS1200 xenon. The GS has great audio, it always works flawless where the Fumeo and Beaulieu are a little picky if things are not recorded just right or aligned with the audio heads perfectly. The list goes on but no doubt the GS Xenon the Fumeo and Beaulieu are considered at the top of list. I think the Beaulieu actually edges ahead of the other two in some ways.

At the end of the day there is no perfect projector. I tried to purchase one of everything not because I want to be able to say I own everything I did so hoping one projector would stand out among the rest as king of the hill. That is not the case. Each has their pros and cons. After all, what matters is what is on the screen. A perfect projector doing its job will always be judged by the quality of the print being run through it.
Consider this, not a single projector can make a bad print look good but a good print can make a bad projector a bit more pleasing.

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 14, 2016 02:26 PM      Profile for Andrew Woodcock         Edit/Delete Post
You have a superb array of tools to work with their Alan.
If you're not happy with the results you get from this little lot, there is absolutely no hope for the rest of us! [Big Grin] [Big Grin] [Wink]

You really ought never to be concerned about the film path on the Beaulieu. Over time I'm certain you come will to appreciate it is as safe as the very best of them Alan.
Just follow the simple step regarding the input guide and everything else with good hygiene, looks after itself! [Smile]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Paul Adsett
Film God

Posts: 5003
From: USA
Registered: Jun 2003


 - posted April 14, 2016 06:49 PM      Profile for Paul Adsett     Send New Private Message       Edit/Delete Post
quote:
At the end of the day there is no perfect projector
Words of wisdom Alan, words of wisdom [Smile]

But your stable of projectors is as close to perfect as can be got on super 8mm, and you have the satisfaction of knowing that any one of your machines is showing your prints at the best that can possibly be obtained.
Regarding the Eumig 926GL, I have found it to be capable of fabulous quality stereo re-recordings, even if you don't use it for any other purpose. If the projector is warmed up running for about 30 minutes it will stay at a very constant speed, so only very minor speed adjustments are necessary whilst recording, and it is very easy to get very good sync over a 10 minute section of film.

--------------------
The best of all worlds- 8mm, super 8mm, 9.5mm, and HD Digital Projection,
Elmo GS1200 f1.0 2-blade
Eumig S938 Stereo f1.0 Ektar
Panasonic PT-AE4000U digital pj

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 14, 2016 06:55 PM      Profile for Andrew Woodcock         Edit/Delete Post
I was able to do cartoons myself on the S938 Paul, and they turn out brilliant for sound!

Just struggled enormously for 600ft reels of film.

It's a similar story with the Goko RM 8008 but for entirely different reasons. If only it had sprockets!!

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Alan Gouger
Master Film Handler

Posts: 451
From: Florida
Registered: Jun 2003


 - posted April 14, 2016 08:44 PM      Profile for Alan Gouger   Email Alan Gouger   Send New Private Message       Edit/Delete Post
quote:
Just struggled enormously for 600ft reels of film.

Andrew and Paul the Eumig is one projector that would benefit from a full play unit.

The Beaulieu I purchased came with dual gates one 16x9 the other 4x3 for scope titles.
Here is a picture of the movie Spiderman projected using the 16x9 gate. The idea is to view the movie matted as it was projected in the cinema. I shot this image off center so it is somewhat skewed.

 -

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 15, 2016 04:09 AM      Profile for Andrew Woodcock         Edit/Delete Post
Top Drawer Alan! And a stunningly beautiful print to boot! [Wink]

I think they introduced the 16:9 gate to match their later cameras with the same optional gate for panoramic type home movies, if I remember correctly.

Beaulieu always seemed to place the greatest emphasis in use of their equipment on movies that were home produced.

All of their sales brochures for their projectors speaks only of their facilities to match their camera's capabilities.

Even the two blade shutter was only introduced to facilitate video transfer of home movies if you read the sales spiel on these.

Maybe that's why optical sound facilities were never considered necessary or relevant by Beaulieu.

Ironically, many I bet, never used these machines with camera shot footage.

The HTI would have been one hell of an investment to view your holiday home movie memoirs on! [Big Grin] [Big Grin]

Still, judging by the standard of the very best cameras they produced, these were intended for serious film maker use, not for the casual home movie maker.

Beaulieu focussed as a company, almost entirely on cameras and film making. The projectors were just an add on it would seem.
A similar story with Braun.

An exceptionally good "add on" though, all the same in both cases!

[ April 15, 2016, 09:04 AM: Message edited by: Andrew Woodcock ]

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Alexander Vandeputte
Expert Film Handler

Posts: 243
From: Belgium
Registered: Nov 2009


 - posted April 15, 2016 09:30 AM      Profile for Alexander Vandeputte   Email Alexander Vandeputte   Send New Private Message       Edit/Delete Post
Alan, curious to see how you switch out the gates. Is it a complicated task or can it be done on the fly just as in 35mm ?

 |  IP: Logged

Alan Gouger
Master Film Handler

Posts: 451
From: Florida
Registered: Jun 2003


 - posted April 15, 2016 12:11 PM      Profile for Alan Gouger   Email Alan Gouger   Send New Private Message       Edit/Delete Post
Very good reasoning Andrew I think you are correct about Beaulieu's strategy. If the 708 was not their main focus then we are even more lucky to have this fine projector available to us.

Alexander it is very easy to change out the gate it just snaps in and out of place. I was sent a very short video showing how to do this, maybe I will upload this video and post the link tonight or tomorrow.
I was also just sent a video how to change the shutter between 2 and 3 blade I will post that as well even though a few good friends on this forum already told me how to do so:)

Edit:
Here are a few videos, I hope the links work for everyone.

Beaulieu, 16x9 to 4x3 gate change
https://www.youtube.com/watch?v=5XS8ROooHDw

Beaulieu, Changing from the 3 to 2 blade shutter position.
https://www.youtube.com/watch?v=SNQMujHuhT8

[ April 15, 2016, 01:40 PM: Message edited by: Alan Gouger ]

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 18, 2016 11:08 AM      Profile for Andrew Woodcock         Edit/Delete Post
Alan, this video appears to show you adjusting the shutter from 3 to 2 blades from the rear of the machine with the rear cover removed.

Is my assumption above here correct?

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged

Paul Browning
Phenomenal Film Handler

Posts: 1006
From: West Midlands United Kingdom
Registered: Aug 2011


 - posted April 18, 2016 11:58 AM      Profile for Paul Browning   Email Paul Browning   Send New Private Message       Edit/Delete Post
What does the 16 x 9 gate achieve ?, you still have to use a scope lens to project it surely, very curious about this. The video shows you clicking in the gate so the lens holders is modified too. Do wittner do the lens holder part ?. I would like to get one to modify to take the Elmo f1.0 lens, there is only .10mm difference between the barrel size's and the elmo will just fit in the little semi circular indent in the casing.

 |  IP: Logged

Alexander Vandeputte
Expert Film Handler

Posts: 243
From: Belgium
Registered: Nov 2009


 - posted April 18, 2016 01:08 PM      Profile for Alexander Vandeputte   Email Alexander Vandeputte   Send New Private Message       Edit/Delete Post
The gate change is impressive, just as in 35mm machines. A 16/9 gate is a very practical thing when projecting 'recent' features that are printed full aperture and need a proper gate to be projected in the correct aspect ratio (Silence of the lambs, Gremlins, Roger Rabbit)

Indeed I find the shutter adjustment method shown, somewhat peculiar. But I guess that's because this HTI model has a douser that does not allow you to acces the shutter from the front side ?

 |  IP: Logged

Alan Gouger
Master Film Handler

Posts: 451
From: Florida
Registered: Jun 2003


 - posted April 18, 2016 11:45 PM      Profile for Alan Gouger   Email Alan Gouger   Send New Private Message       Edit/Delete Post
quote:
Alan, this video appears to show you adjusting the shutter from 3 to 2 blades from the rear of the machine with the rear cover removed.

Is my assumption above here correct?

Yes Andrew that is correct. Alexander was correct why it is done this way.

quote:
Indeed I find the shutter adjustment method shown, somewhat peculiar. But I guess that's because this HTI model has a douser that does not allow you to acces the shutter from the front side ?
Hello Alexander yes you guessed it correct:)

quote:
What does the 16 x 9 gate achieve ?
Paul read Alexanders answer for this. This projector came with two gates one is 16x9 and one is full frame which is used for older titles meant to be screened as 4x3. You will also use the full frame gate for scope titles.

If you are interested in any of these mods I am sure it can be done. Contact serv@s8profis.de
S8 profis

 |  IP: Logged

Andrew Woodcock
Film God

Posts: 7477
From: Manchester Uk
Registered: Aug 2012


 - posted April 19, 2016 02:48 AM      Profile for Andrew Woodcock         Edit/Delete Post
Thanks Alan. its just as well that people with these will probably be keeping the machine in 2 blade shutter config more often than not then.

Something of an oversight there on Beaulieu's behalf regarding the design teams decision to engineer this model in such a way that you have to remove the rear cover just to change the shutter over from 3 to 2 blades.

The douser though, is a necessity for these, so I suppose they were left with little option aside from changing the lamphouse cover design completely just for the HTI models.

--------------------
"C'mon Baggy..Get with the beat"

 |  IP: Logged
