Topic: Eumig Mark S802 bulb?

Stephen Kent Jusick
Junior
Posts: 18
From: New York, NY, USA
Registered: Jan 2004

posted May 21, 2008 02:09 AM

What kind of bulb do I need for a newly acquired Eumig Mark S802 projector?
I know it's 12 volt/75 watts, but what's the ANSI code?
I was looking at topbulb.com but there are several that seem
like they COULD be right, EFN, EYC, EYF, EYJ. Any ideas?

Thanks!

Stephen Kent Jusick
New York

| IP: Logged

Hugh McCullough
Expert Film Handler

Posts: 156
From: Old Coulsdon. Surrey. UK
Registered: Oct 2006

posted May 21, 2008 06:50 AM

Hello Stephen.
According to the instruction book the lamp is an A1/231 12Volt 100Watt EFP.

Go to this site for more information.
http://www.donsbulbs.com/cgi-bin/r/b.pl/12%7C100w~eumig.html

--------------------
EIKI Ex 6100 xenon machine.

| IP: Logged

Jan Bister
Darth 8mm

Posts: 2629
From: Ohio, USA
Registered: Jan 2005

posted May 21, 2008 08:19 AM

Negative... the correct lamp is an A1/230 12V 75W, also known as an EFN, EYF or EYC as far as I can determine (they're all the same).

--------------------
Call me Phoenix. *dusts off the ashes*

| IP: Logged

Hugh McCullough
Expert Film Handler

Posts: 156
From: Old Coulsdon. Surrey. UK
Registered: Oct 2006

posted May 21, 2008 04:43 PM

Sorry Jan, maybe I can not read correctly, but the instruction book plainly states:-
Required Lamp: 12 volt, 100 watt tungsten-halogen with diathermic reflector, order No 931.004/6

--------------------
EIKI Ex 6100 xenon machine.

| IP: Logged

Sam J. Clarke
Junior
Posts: 28
From: Newcastle, England
Registered: May 2008

posted May 21, 2008 05:26 PM

Hello,

I think there are two types which might be the confusion:

Eumig Mark S 802 D which is 100w 12v
Eumig Mark S 802 which is 75w 12v

Sam

| IP: Logged

Hugh McCullough
Expert Film Handler

Posts: 156
From: Old Coulsdon. Surrey. UK
Registered: Oct 2006

posted May 21, 2008 06:07 PM

You are quite correct Sam.
There are two models, but my instruction book states that the 12 volt 100 watt lamp is used in both the S802, or the S802D.
Apparently there is a 75 watt bulb that fits this projector, but it is not the lamp recommended by Eumig

http://www.donsbulbs.com/cgi-bin/r/b.pl/efn%7c12v%7c75w~ansi.html

--------------------
EIKI Ex 6100 xenon machine.

| IP: Logged

Stephen Kent Jusick
Junior
Posts: 18
From: New York, NY, USA
Registered: Jan 2004

posted May 21, 2008 06:42 PM

Hmm..
The projector I have says right on the back that the bulb is "max. 75watt 12 volt." That's where I got the info originally. But I didn't have the ANSI code....

I appreciate everyone's help.

How can the EFN, EYF or EYC bulbs be the same? They seem to have different prices...

EFN has a Base Type GZ6.35and a Color Temp of 3400K
EYF has a Base Type GX5.3 and a Color Temp of 3050K
EYC has a Base Type GX5.3 and a Color Temp of 3050K

Any more ideas or actual experiences with this projector and bulb(s)?

Thanks!

Stephen Kent Jusick

| IP: Logged

Sam J. Clarke
Junior
Posts: 28
From: Newcastle, England
Registered: May 2008

posted May 21, 2008 06:53 PM

The EFN one is the correct one I think because it has the same base size GZ6.35 as my projectors and the link http://www.donsbulbs.com/cgi-bin/r/b.pl/efn%7c12v%7c75w~ansi.html which Hugh McCullough posted says it's correct too.

Sam

| IP: Logged

David Kilderry
Jedi Master Film Handler

Posts: 963
From: Melbourne, Victoria, Australia
Registered: Feb 2006

posted May 22, 2008 03:55 AM

Did they upgrade the lamp during the model run? I think I have owned models of the S 802 that have had both installed. I always replaced the lamp specified on the lamphouse or instructions.

In the late 1970's almost every quality projector was at 100w so perhaps they moved up to this lamp and added a slightly different power supply?

David

| IP: Logged

Jan Bister
Darth 8mm

Posts: 2629
From: Ohio, USA
Registered: Jan 2005

posted May 22, 2008 10:13 AM

Hmm. All of you seem to be right... this is a bit of a mystery it seems. The reason I was saying go for the 12V/75W bulb was just in case the transformer in your particular Eumig machine can't handle 100W and might burn out from prolonged use with a 100W bulb. So while I certainly don't think Hugh can't read [Roll Eyes]

the question remains, do you wanna stick with an EFN bulb or go for the EFP one? The safest way to answer this would be to simply look at any stickers on the back or inside the machine (near the lamp holder) that say "12V/100W" or "12V/75W" and just go by that...

--------------------
Call me Phoenix. *dusts off the ashes*

| IP: Logged

Michael O'Regan
Film God

Posts: 3085
From: Essex, UK
Registered: Oct 2007

posted May 22, 2008 10:26 AM

I have quite a few ELC 24V/250W for sale - if you want to give it a go!!!!!!!!!!!!!!!!!
Go on, be a devil....

[Big Grin]

| IP: Logged

Josef Grassmann
Expert Film Handler

Posts: 190
From: Hennef-Sieg, Germany
Registered: Apr 2005

posted May 22, 2008 10:54 AM

Eumig projectors have a label on back cover (bottom, right).
There they state Projector Type and voltage and bulb data: e.g.
220/250 ~ 50Hz, 175 Watt Pr. Lampe max. 100W 12V

Pr. Lampe = projection bulb

Look at the label. It should be 12v 100W max. for Eumig Mark S 802, too

| IP: Logged

Paul Adsett
Film God

Posts: 5003
From: USA
Registered: Jun 2003

posted May 22, 2008 11:06 AM

I think David is right- early models of the S802 used the 75 watt bulb, later models use the 100 watt bulb. My 802 and 820 both use the 100 watt bulb. But if the projector has a lable saying 75 watt bulb, it means the transformer is sized for 75 watts NOT 100 watts.

--------------------
The best of all worlds- 8mm, super 8mm, 9.5mm, and HD Digital Projection,
Elmo GS1200 f1.0 2-blade
Eumig S938 Stereo f1.0 Ektar
Panasonic PT-AE4000U digital pj

| IP: Logged
