Topic: Eumig 610D focus knob issue

Zach Von Joo
Film Handler

Posts: 33
From: San Francisco
Registered: Sep 2010

posted June 17, 2012 06:24 PM

Hi There--

I can't get the lens to stay in place in one of my Eumigs... Focus knob is stripped? The plastic spiral on the inside of the knob does not move along with the focus knob.

Has anyone had any experience fixing this problem?

Thank you,

Zach

| IP: Logged

Hugh Thompson Scott
Film God

Posts: 3063
From: Gt. Clifton,Cumbria,England
Registered: Jan 2012

posted June 17, 2012 06:27 PM

You'll have to let us know the model of your projector.

| IP: Logged

Zach Von Joo
Film Handler

Posts: 33
From: San Francisco
Registered: Sep 2010

posted June 17, 2012 06:31 PM

It's in the topic-line: Mark 610D

Thanks!

| IP: Logged

Hugh Thompson Scott
Film God

Posts: 3063
From: Gt. Clifton,Cumbria,England
Registered: Jan 2012

posted June 18, 2012 05:13 PM

Sorry Zach,can't see the wood for the trees.Is it the pin on the
lens that is worn and not locating with the worm on the focusing
knob?

| IP: Logged

Zach Von Joo
Film Handler

Posts: 33
From: San Francisco
Registered: Sep 2010

posted June 18, 2012 07:11 PM

No, it's that the worm on the focusing knob does not turn when I turn the knob. The pin in the lens is okay I think. Does this mean it's broken inside somewhere? Can it be fixed?

Thanks!

| IP: Logged

Joerg Wittgen
Junior
Posts: 8
From: Gelsenkirchen,Germany
Registered: Jun 2012

posted June 18, 2012 10:16 PM

hi
I think that the focus button is pushed onto a splined axle.
could be that these ripple-axis is worn.
maybe stick with superglue the focus knob on the axle?
I only know the 900 series of Eumig.
there is a splined axle.
The focus knob is only pushed on this axle.

--------------------
"Terrific, let's do it again" "Faster and more intense"

--George Lucas--

| IP: Logged

Zach Von Joo
Film Handler

Posts: 33
From: San Francisco
Registered: Sep 2010

posted June 18, 2012 11:05 PM

Joerg-- Okay, I think I understand you on this, that makes sense about the contact between the knob and the axle being worn down. I should then remove the focus knob somehow to get to the axle? I don't want to break anything. I'll take a look at it later tonight & see if I can figure it out how to do that correctly.

| IP: Logged

Joerg Wittgen
Junior
Posts: 8
From: Gelsenkirchen,Germany
Registered: Jun 2012

posted June 18, 2012 11:21 PM

please be careful!
I know this only from the 900 series.
try it with non-violent.
old plastic can break like glas

Edit:
I've just seen a picture.
under the cover are four screws.i think the entire plate can be removed with the focus knob.but im not sure.
look at the picture:

--------------------
"Terrific, let's do it again" "Faster and more intense"

--George Lucas--

| IP: Logged

Lee Mannering
Film God

Posts: 3216
From: The Projection Box
Registered: Nov 2006

posted June 19, 2012 02:07 AM

On the 610D the outer sleeve of the focus knob is fixed with a light glue to a inner plastic knob. After so many years it does not usually take much to get the outer silver sleeve off. Once this is off you should be able to see the problem which I expect is just a un glued outer which needs sticking back on to its inner if you get my drift.

| IP: Logged

Zach Von Joo
Film Handler

Posts: 33
From: San Francisco
Registered: Sep 2010

posted June 19, 2012 02:43 AM

Lee--

I got the outer sleeve of the knob off, there's a spindle with a metal pincher-looking fastener stamped on it... it looks as if that's supposed to be attached to the plastic beneath, but the plastic there has deteriorated. Hmmm... I need to figure out a way to reattach the fastener thing to the rest of the knob & I'll be okay. Some kind of pin or something.

Thanks for all the help on this! I hope my description makes sense.
