Topic: What kind of reel is this?

Dan Esmond
Junior
Posts: 16
From: Lawrence, KS, USA
Registered: Oct 2013

posted October 09, 2013 08:32 PM

Hi all... So glad to have found this place. I am a total novice when it comes to film and am embarking on a project to telecine all of my family's old home movies via my DSLR. I recently picked up a Chinon 2500GL and have been having fun playing with that. I am sure I will have more questions as I delve into this project, but to start... Does anyone recognize the type of reel in this picture? My understanding is that both regular 8mm and Super 8 use a circular hole with three notches (just different sizes). This one looks square shaped, and has two notches, which are not even aligned on both sides of the reel! It definitely has an 8mm film wound on it (see the small piece I placed in the photo).

The problem is I can't get the reel to fit on the projector's supply arm due to the notch differences. I have ordered a spare 400ft reel I guess I could wind it onto. I wondered also about trying to cut out a third notch to try to make it fit.

But before I do anything I thought I would ask you fine people to see if you had any ideas as to what that reel was designed to fit.

Thanks guys! I am loving playing with all this stuff.

| IP: Logged

Clinton Hunt
Jedi Master Film Handler

Posts: 845
From: Waharoa,North Island,New Zealand
Registered: May 2010

posted October 09, 2013 09:37 PM

It is a 16mm film reel but must've been altered to allow a 8mm film to fit on it?
I do have one that has been altered for a 9.5mm film with two extra holes to hold the reel [Wink]

--------------------
Cheers from me in New Zealand :-)

| IP: Logged

Pasquale DAlessio
Film God

Posts: 3523
From: Bristol,RI, USA
Registered: May 2010

posted October 09, 2013 10:29 PM

Dan

WELCOME TO THE FORUM!!

PatD

| IP: Logged

Winbert Hutahaean
Film God

Posts: 5468
From: Nouméa, New Caledonia
Registered: Jun 2003

posted October 09, 2013 10:53 PM

Hi Dan,

Your concern has been raised here:

Does this reel fit on ST-1200?

--------------------
Winbert

| IP: Logged

Maurice Leakey
Film God

Posts: 5895
From: Bristol. United Kingdom
Registered: Oct 2007

posted October 10, 2013 02:33 AM

The film shown is standard (regular) 8, your projector is a dual gauge machine, but it will need a Super 8 spool for its take-up.

The spool shown is a 16mm which appears to be modified for use on a standard 8 projector. Note that it will not fit on a Super 8 spindle due to the fact that Super 8 spools have a larger hole.

--------------------
Maurice

| IP: Logged

Dan Esmond
Junior
Posts: 16
From: Lawrence, KS, USA
Registered: Oct 2013

posted October 10, 2013 11:34 AM

Thanks guys for the welcome and helpful info. I wish my grandfather were still around to ask why he used such a reel to hold an 8mm film since it won't fit on an 8mm projector! Ah well, I will thread it onto a standard reel so I can watch it.

I'm sure I will be back with more questions. In the meantime I will keep reading and learning here. Thanks again.

| IP: Logged
